Product Introduction:
Heavy-duty four-process cutting machine
Machine model: MD1325(appearance is for reference, subject to reality)
Main functions: The cabinet connection is suitable for connection methods including ordinary three-in-one, Le buckle invisible parts, slotted slide button invisible parts, Lamino invisible parts, etc. Special-shaped sheet, automatic punching, slotting. Automatic material cutting, one-key vacuuming and pushing materials, etc. The software automatically disassembles the order, optimizes the typesetting, reduces waste, and integrates design and processing.
Applicable scope:
It is suitable for custom cabinets, wardrobes, paint-free doors, cutting materials, paint doors, plastic doors, furniture, home decoration, woodworking decoration, wooden crafts, wooden doors, screens and other industries.
Machinable materials:
All kinds of solid wood, particle board, ecological board, MDF and other non-metallic materials.
Product Advantage:
1. Save labor cost, simple operation mode, after 3-6 days of on-site practical operation training, you can be proficient in automatic drawing and automatic typesetting.
2. To improve the utilization rate of plates, the unique special software for intelligent typesetting can generate orders and tool paths for various types and styles of drawings at
one time, allowing you to save plates to the best extent, and the average utilization rate of each plate is 95%.
3. The adsorption of the vacuum device is strong and powerful, and the vacuum adsorption effect of the porous position is good, which prevents the misalignment of the plate
during cutting, and can perfectly absorb small pieces of material; it solves the problem of poor adsorption effect when processing small-sized workpieces in the industry;
4. Safe and reliable operation; the unique X, Y, and Z three-axis limit safety protection system avoids safety problems such as gantry limit caused by drawing errors during equipment processing, making your operation safer and more reliable;
5. The dust collection device is excellent; the advanced dust collection cover sealing system, because of the good dust collection effect and powerful power, can prevent the
phenomenon of dust flying all over the place in your processing workshop; (150mm)
6. Plate automatic positioning; the machine is equipped with a cylinder positioning function to ensure that each plate is placed in the same position, and there will be no
repeated definition of the workpiece origin. When lifting, the machine stops working automatically to prevent the cylinder from being cut and the machine and cutter from being
damaged.
Technical Parameters:
Item | Features | Description |
1 | Control system | Taiwan Baoyuan (MW2200A) with hand wheel Taiwan LNC (MW2200A) Handwheel/Optional Taiwan new generation system 60CA |
2 | working voltage | 380V±5% 50HZ1±1% |
3 | Dimension | 4000*2300*2500mm |
4 | Working size | 1830*2800mm (support customized size Customized size available), The maximum feeding height is 70mm. |
5 | Machine structure | Heavy duty with six leg, high temperature quenching |
6 | Machine processing method | Automatic 5 side machining with accuracy is 0.002mm |
7 | Drive parts | X, Y high-precision rack and pinion drive Z-axis lead screw, Y-axis German SLM30 guide rail with Flange slider. |
8 | Rack | Rack polishing BBOSIICH |
9 | Rail guide and rack installation error | Less than 0.05mm |
10 | Z axis parts | Z axis is Leisai 1500w servo motor with holding brake |
11 | Z axis fixed method | Adopt integrated motor screw rod bearing C & U |
12 | Z axis screw rod | Taiwan TBI |
13 | Motor group | Leisai 1500w servo |
14 | Reducer | GPG high precision reducer |
15 | Main spindle power
| 6KW*4 German UFC spindle 6KW*4 ， 18000r/min(选配 24000r/min) |
16 | Frequency converter | Fuling |
17 | Working table structure | High quality Thickened ABS with brownish red color |
18 | Subregion | Vacuum table with 6 subregion |
19 | Vacuum power | 11kw Water cooled high power vacuum pump |
20 | Dust collector method | Spindle automatic partition dust collector |
21 | Tool setting method | Thousand classification automatic tool setting instrument |
22 | Electrical components | Schneider France |
23 | Cable | German high flexible double protection full shield cable |
24 | Position system | Right angle panel position system |
25 | Unloading function | Double air automatic pushing (with secondary dust collection) |
26 | Loading function | Customization |
27 | Auxiliary function | Side emergency stop button, positioning cylinder and dust collector |
28 | Machine cabinet | Independent large cabinet with four fans circulating cooling mode |
29 | Appearance | The whole machine is industrial design appearance , beautiful and generous surrounding |
30 | Working speed | Limit speed can reach 80 m / min |
31 | Software | Support G code / Code: (NC), MMG, PLT, Eng, DXF dismantling software or door panel software |
32 | Ｗwarranty period | 1 Year with export quality standards |
Item | Devices name | Reference Pictures | Descriptions |
1 | Control interface |
| High-definition industrial screen, Taiwan Baoyuan system/new generation control interface design is humanized, fool-like operation, operators can start working after simple training, no skilled workers are required. |
1 | Tool setting device |
| Thousand-level high-precision tool setting instrument, repeatability is 0.002mm, IP68 protection level, 3 million contact life, 304 stainless steel cable protection hose, outer cover protection box. |
2 | Vacuum table and adsorption |
| High-quality ABS rubber soleplate, cold and heat resistant, no deformation or burst due to temperature difference between north and south. 24 vacuum channels for powerful suction. There are 6 vacuum zones, which can be opened and closed freely, and both large and small plates can be well adsorbed. |
3 | Spindle motor |
| Air-cooled high-frequency spindle maximum speed 18000r/min |
4 | towline |
| A new type of towline is adopted, with internal compartments, to separate signal lines and power lines according to specifications, to better defend against signal interference, and to prevent cables from being twisted together during work. The cable uses High flexibility shielded wire, longer service life. |
5 | control box |
| The important electrical components in the control cabinet are all imported from Schneider; Equipped with a filter to eliminate interference and ensure the stability of the control system. |
6 | servo motor |
| The servo drive adopts Leisai 1500W high-power servo motor, which has the highest performance of high-speed, high-precision transmission, and the maximum torque of the motor can reach 350%. |
7 | Push the material and vacuum the second time. |
| Pushing device with vacuum system, automatic cleaning table with automatic grab function, automatic positioning. |
8 | Centralized lubrication system |
| The intelligent central centralized lubrication system is used to support the volumetric shunt system, so that the equipment's sliders, rails and other motion systems can be automatically maintained, and the oil circuit design can be adjusted to ensure the supply of lubricating oil at each oil filling point and extend the service life of the equipment. |
9 | bed frame |
| It is welded with square steel and tempered to eliminate welding stress and ensure that it will not deform after many years of use. The reinforcement ribs of the bed are relatively dense, which increases the strength of the bed and ensures that the bottom plate does not deform. |
10 | structure |
| The bed has been precisely calculated to ensure the operator's material turning speed and positioning accuracy, which is more than twice that of peer equipment without any error. The high-rigidity body structure is designed and passed Material stress analysis and fire treatment make the precision of the machine permanent and not deformed. |
Q1. Are your trading company or factory?
A1. We are factory with more than 20000m2 workshop located in Shunde Dist., Foshan, Guangdong, China.
Q2. What machine can you supply?
A2. Our main machines are computer beam saw, edge banding machine, cnc drilling machine, cnc router machine etc.widely used for panel furniture production.
Q3. What is the payment term?
A3. T/T 30% in advance and balance before shipment, LC or by negotiation.
Q4. What is the delivery time?
A4. Normal 380V voltage is 15-30 days, other voltage is 30-45days.
Q5. What is the guarantee?
A5. 12 months for the whole machine. Within 12 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 12 months, you will get spare parts at cost price.You will also get technical support and service all the lifetime.
Q6. Can you support the pre-sales service before confirm the order?
A6. Yes ,you will get experienced pre-sales engineer to support, not only including machine and auxiliary selection but also electrical ,air, machine layout in factory ,etc.
Q7. What is the after sales services?
A7. you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by online tools. We can also send our engineer to your factory, but need you take charge of all travelling cost and labour cost.
