Automatic CNC beam saw
Series MJ330P
Spec In details
Material Iron stell
Brand E-FIND
Model MJ330P
Consult Immediately
Order Now
DetailRelated ProductsReview(0)



Product introduction.jpg


Product Introduction:

Product name: Fully automatic computer panel saw


Product model: MJ330P


Workflow: Import the cutting order and size into the system - the material calculation software automatically generates the required cutting information - the material calculation software optimizes the combination based on the generated cutting information - the system generates a cutting diagram ---Generate corresponding documents (such as picking lists, remaining material storage orders, etc.) and generate corresponding barcode information----cutting data enters the electronic cutting saw----electronic cutting saw----prints the barcode ----Attach barcode---flow to the next process


Features:


1. Automatically detect the cutting length of the board, automatically adjust the sawing time according to the cutting specifications, shorten the sawing cycle and improve work efficiency;


2. It has a built-in plate optimization function. You can directly copy the data to a USB flash drive or import it remotely by connecting to wifi. After receiving the material bill, you can directly disassemble the bill of materials and automatically calculate the number of panels that need to be cut, making it convenient for procurement and planning of panel procurement. Reduce waste and surplus;


3. The board optimization software automatically optimizes the size of the cutting board, automatically generates cutting diagrams, improves board utilization, and automatically imports the optimized data into the cutting saw control system. It can simultaneously print barcode labels to facilitate back-end process identification and docking. Back-end CNC equipment;


4. Automatically feed the board, automatically position the cutting size according to the cutting requirements, automatically push out the board after cutting the previous one and position the size of the next board to be cut, and continue cutting. The feeding adopts imported planetary reducer and grinding grade gear and rack to perform precise positioning and precision compensation, and the error can be as low as ±0.15mm;


5. The saw truck runs smoothly on the linear precision guide rail and automatically moves forward and backward for cutting. The guide rail is installed close to the "U" shape of the machine body. It has excellent straightness and does not need to adjust the machine. The large and small saw blades are forward and backward, the cutting edge is smooth, and the edge sealing effect is good.


6. The whole machine weighs 6 tons, the steel plate on the fuselage table is 25mm thick, and the frame is not easily deformed. It is not easy to generate vibration during the automatic sawing process, and the machine body is stable to ensure the accuracy of the machine saw.



product description.jpg


Applicable scope:

It is suitable for custom cabinets, wardrobes, paint-free doors, cutting materials, paint doors, plastic doors, furniture, home decoration, woodworking decoration, wooden crafts, wooden doors, screens and other industries.
Machinable materials:

All kinds of solid wood, particle board, ecological board, MDF and other non-metallic materials.

Product Advantage:


1. For parameterized input of size, simply input the dimensions required for cutting (such as length, width, and quantity) into the touch screen of the machine. After placing the plate, start the machine to run automatically and the input size and quantity can be cut out. No manual intervention is required during the cutting process, just wait for the material to be discharged, low labor intensity and safe;


2. The machine automatically clamps the plate for positioning and cutting, controlled by a high-precision servo system. It is equipped with an imported planetary reducer and a grinding-grade rack and pinion transmission. The positioning error is as low as ±0.02mm, and the sawing error is as low as ±0.15mm. The accuracy is very high. Accurate, providing convenience for subsequent workstations.


3. The main saw sawing motor is 15KW, with high power, sufficient horsepower, and powerful cutting. When cutting, the saw truck runs smoothly on the linear precision guide rail without jumping edges, layers, or saw burning. The saw base has been dynamically balanced and rotated through testing to ensure smooth operation.


4. The whole machine is reinforced and welded with high-quality steel. The thickness of the main machine table steel plate is 25mm. The whole machine weighs 6 tons. It can withstand the heavy pressure of the plate and is not easy to vibrate during high-speed cutting. It is solid and stable, ensuring that the body does not deform and has excellent performance for a long time. cutting accuracy.


5. There is no need to hire a professional cutting master for cutting materials. General workers can start cutting materials after simple training, eliminating reliance on skilled workers and solving problems such as difficulty in employment and recruitment for enterprises.




product Specifition.jpg

Technical Parameters:

型号:

MODLE

MJ-330P

锯切长度

Max.Cutting lenght

3300或2700MM(议定)

副锯片外径

Vice saw blade diameter

180mm

锯切厚度

Max.Cutting thickness

100MM

副锯轴直径

Sub shaft diameter

30mm

定位方式

Positioning method

自动Automatic

副锯转速

Secondary saw speed

6100r/min

定位精度

Positioning accuracy

±0.02mm

送料速度

Feeding speed

0~120M/min

锯切精度

Cutting accuracy

±0.15mm

机械手伺服电机

Mechanical hand servo motor

1.5kw

主锯电机功率

Main saw motor power

15kw

锯切速度

Cutting speed

0~80M/min

主锯片外径

Main saw blade diameter

400mm

回程速度

Return speed

0~120M/min

主锯轴直径

Main shaft diameter

60mm

空气压力

Air pressure

0.6-0.7MPA

主锯转速

Main saw speed

5100r/min

机床外形尺寸

Machine tool dimension

5500MM×6100MM

锯车伺服电机功率

Saw car servo motor power

1.5kw

净重

Net weight

约5800KG

总功率

Total power

22kw




product details.jpg




Item

Devices name

Reference Pictures

Descriptions

1

20'' PC control system



1. Easy operation, safety & reliable. 2. Which has complete operating hints and troubleshooting guide functions. 3. It’s cutting plan can edit manually; can simulate or execute cutting plans. 4.Can compatible with bar code manage software or factory automation software.

1

Cutting optimization software and laber Printer


Optimization software: Automatically generate the optimazation sawing solution, can save personal calculation time and enhancing material utilization efficiency, which can save labor cost, material and inhance the efficiency.

2

PLC



Japan Mitsubishi PLC control system.

3

Side aligning device


Fix cutting panel width side, control panels not move or shake when sawing, ensure width sawing precision. Pressure can be adjusted according to difference thickness, weight and material, ensure the precision of sawing dimension.

4

Main steel frame


Main surface bending by 22mm thick steel, adopting advanced CO2 gas shielded arc welding technology, ensure frame non-deformation, high efficiency and stable quality.

5

Lubricating system


Auto lubricating for machine body, very convenient, can prolong the machine’s service life and keep good accuracy

6

Saw blades


1). Two saw blades ensure cutting precision.

2). Main saw blades 20HP, max cutting thickness: 100mm.

3). Saw blades gears: Germany SKF;

4). Sawing motor: TAIWAN SANYE;

7

Saw carrier



1). Driven by imported TAIWAN FENGMAO high-precision rack & pinion, stable movement, ensure cutting precision.

2). Saw carrier pull back position automatically controlled base on next cutting length, Which reduce unused moving time and greatly improve efficiency.

3). Max cutting speed reach to 100m/min.

8

Loading system



Air floating loading table,avoiding board scratching and assuring smoother board movement, suit for heavy and big type wood panel.

9

Feeding gripper



Equip 7pcs pneumatic holding gripers, can gripe the panel steadily, highly reduce labor intensity, and greatly improve production efficiency, Min holding panel size 45mm.

10

Structure


The bed has been precisely calculated to ensure the operator's material turning speed and positioning accuracy, which is more than twice that of peer equipment without any error. The high-rigidity body structure is designed and passed.

Material stress analysis and fire treatment make the precision of the machine permanent and not deformed.




Components brand.jpg










exhibition show.jpg






Q1. Are your trading company or factory?

A1. We are factory with more than 20000m2 workshop located in Shunde Dist., Foshan, Guangdong, China.


Q2. What machine can you supply?

A2. Our main machines are computer beam saw, edge banding machine, cnc drilling machine, cnc router machine etc.widely used for panel furniture production.


Q3. What is the payment term?
A3. T/T 30% in advance and balance before shipment, LC or by negotiation.


Q4. What is the delivery time?

A4. Normal 380V voltage is 15-30 days, other voltage is 30-45days.


Q5. What is the guarantee?

A5. 12 months for the whole machine. Within 12 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 12 months, you will get spare parts at cost price.You will also get technical support and service all the lifetime.


Q6. Can you support the pre-sales service before confirm the order?

A6. Yes ,you will get experienced pre-sales engineer to support, not only including machine and auxiliary selection but also electrical ,air, machine layout in factory ,etc.


Q7. What is the after sales services?

A7. you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by online tools. We can also send our engineer to your factory, but need you take charge of all travelling cost and labour cost.
